1.5kw Gasoline Generator
| Product Name | TG2000 | |
| Single-cylinder | 4-stroke | |
| 1.5kw@50Hz | 1.7kw@60Hz | |
| Brush Type | |
| Votage Control | AVR | |
| Start System | Recoil | |
| MOQ | 20 Pcs |
1-Year Limited Warranty
163cc/5.5HP
Gasoline Engine
1.7kw or 1.9kw
Max Power
15L
Fuel Tank
ECO Design
Open Frame
The C.A.G TG2000 Gasoline Portable Generator is powered by 163cc, and is an air cooled, single cylinder, OHV 4-stroke engine that delivers maximum power of 1800 watts at 50Hz and 2000 watts at 60Hz, with a 15L fuel tank this unit can run up to 12 hours at 50% load. Our OHV engine is equipped with a low oil shutdown system and designed for safer and longer operation time and easier maintenance. This gasoline generator is ideal for RV’s, camping trips, tailgating parties, power tools, or home back-up power during emergencies.
| Model | TG2000 |
| Type | Brush |
| Voltage Regulate | AVR |
| Frequency Hz | 50 | 60 |
| Rated AC Voltage (V) | 230V | 120V |
| Rated AC Output (KVA) | 1.5 | 1.7 |
| Peak AC Output (KVA) | 1.8 | 2.0 |
| Power Factor COSφ | 1 |
| Model | TE160 |
| Type | OHV,4-stroke, single cylinder,Air-cooled |
| Bore x Stroke (mm) | 68×54 |
| Displacement (ml) | 163 |
| Max. output (HP/rpm) | 5.5/3600 |
| Fuel Type | Unleaded Gasoline |
| Fuel Tank Capacity (L) | 15L |
| Continuous Operating 1/2 load (h) | 13 |
| Engine Oil Standard | SF or Higher Grade |
| Oil Capacity (L/gal) | 0.6/0.16 |
| Ignition system | C.D.I |
| Starting System | Recoil |
| Operating Noise Level (7m) dB(A) | 67 |
| Dimensions L×W×H (mm) | 610x460x470 |
| Net /Gross Weight (kg) | 35/37 |
| 20/40FT unit | 225 / 475 |
